ADC Elisa 200 System

Model

ADC Elisa 200 System​

Design

Benchtop

Sample Channels

2

Type of Tips

Independently operated dispense channels with disposable tips to avoid carryover

Sample Pipetting principle

Sample pipetting by air displacement

Specification of Tips

300µl and 800µl tips

Pipetting Range | Increment

Range: 5 to 800µl | Increment: 0.1µl

Pipetting Precision and Accuracy

Type of tip    @ Volume   Accuracy   Precision (CV%)

300µl         100µl        ± 1%       <0.75%

800µl         100µl        ± 1%       <0.75%

Sample Carrier

Each standard sample carrier can hold up to 24 tubes

Sample Positions

6×24=144

Reagent Positions

24(60ml)

Incubation

1

Temperature Range

Room temperature to 60°C adjustable at an increment of 0.1°C

Washing Channels

16 wells with 1 plate positions

Washing Plate Positions

1

Residual Volume

≤1ul/well

Tip Carrier

1(384)

Optional Configurations

Different specifications of

tip carrier, tube carrier,etc..

Dimensions WxDxH mm

1290×845×1000

Weight Kg

240
